Air release valve triple effect
Triple effect air release valve. *With inlet filter for water impurities.
| Reference | tooltipImage | characteristics | Box units | measurement | A | B | C | r1dt | r2dt |
|---|---|---|---|---|---|---|---|---|---|
| 093071 | - | BSP | 10 | 3/4" | 50.9 | 119 | 22 | 3/4” | 1/4" |
| 093072 | - | BSP | 10 | 1" | 50.9 | 119 | 22 | 1” | 1/4" |
| 093073 | - | NPT | 10 | 3/4" | 50.9 | 119 | 22 | 3/4” | 1/4" |
| 093074 | - | NPT | 10 | 1" | 50.9 | 119 | 22 | 1” | 1/4" |
| 093086 | - | BSP | 1 | 1 1/2" | - | - | - | - | - |
| 093087 | - | BSP | 1 | 2" | - | - | - | - | - |
| 093088 | - | NPT | 1 | 1 1/2" | 103 | 201.5 | 26 | 1 1/2” | 1" |
| 093089 | - | NPT | 1 | 2" | 103 | 201.5 | 26 | 2” | 1" |
| 193086 | - | BSP *With inlet filter | 1 | 1 1/2" | - | - | - | - | - |
| 193087 | - | BSP *With inlet filter | 1 | 2" | - | - | - | - | - |
