SA UNI

Saddle with outlet spigot Universal SDR 11

Saddle with outlet spigot Universal SA UNI SDR 11

Gas, water and H2

Maximum pressure: Gas 10 bar, Water 16 bar
Material: PE 100
Universal clamping technique (balanced loading):
- Safe clamping with UNITOP
- Ideal distribution of force application
- Perfect adaptation to pipe diameter
Pressure test of the fusing before tapping possible
Tapping under pressure possible
Safety technology

Note:

When processing SA UNI with outlet spigot 90 - 160, the clamping device UNITOP (Order No. 613385) is required.

For the outlet spigots 225 / 250, UNITOP 250 (Order No. 613387) is required.

For pressure-free tapping, we recommend our FWAB drilling device.

Pressure test of the fusing before tapping with pressure test adapter FWDPA SA (Order No. 613596).

Also suitable for special dimensions for Close-Fit-Liners.

If you have any questions about this or about tapping under pressure, please contact our Hotline: Tel. +49 621 486-2325.

Go back Data sheet

PE 100 SDR 11

Maximum permissible working pressure 16 bar (water) / 10 bar (gas)

	Reference	d₁	d₂	BX	PU	L	t	B1	Drilling Ø d_a	Weight [kg]
	616553	250-280	90	5	40	130	79	260	65	1,420
	616554	250-280	110	5	40	140	82	260	84	1,590
	616555	250-280	125	5	40	146	87	260	95	1,760
	616556	250-280	160	5	40	158	98	260	123	2,210
	616557	315-400	90	5	40	130	79	280	65	1,430
	616558	315-400	110	5	40	140	82	280	84	1,600
	616559	315-400	125	5	40	146	87	280	95	1,750
	616560	315-400	160	5	40	158	98	280	123	2,220
	616561	450-900	90	5	40	130	79	307	65	1,390
	616562	450-900	110	5	40	140	82	307	84	1,550
	616563	450-900	125	5	40	146	87	307	95	1,710
	616564	450-900	160	5	40	158	98	307	123	2,160
¹	617224	315-355	225	5	40	226	164	363	172	2,210
¹	617225	315-355	250	5	40	226	164	363	187	2,210
¹	617226	400-450	225	5	40	226	164	403	172	2,210
¹	617227	400-450	250	5	40	226	164	403	187	2,210
¹	617228	500-560	225	5	40	226	164	429	172	2,210
¹	617229	500-560	250	5	40	226	164	429	187	2,210
¹	617230	710-900	225	5	40	226	164	444	172	2,210
¹	617231	710-900	250	5	40	226	164	444	187	2,210
¹	617232	1000-1200	225	5	40	226	164	450	172	2,210
¹	617233	1000-1200	250	5	40	226	164	450	187	2,210

¹ NEW

Areas of Application

Instead of cost-intensively integrating a T-piece, a branch or vent can be very comfortably created using the FRIALEN Saddle with outlet spigot Universal SA UNI. The spigot outlet can be fused with FRIALEN couplers MB or UB.

Assembly Instructions

The saddle SA UNI is clamped onto the pipe with the UNITOP clamping device (Order-No. 613385, see FRIATOOLS product range) or for the saddle SA UNI 225/250 with the UNITOP 250 clamping device (Order-No. 613387). The clamping device UNITOP or UNITOP 250 is an universal tool for all SA UNI dimensions. Please read the assembly and operating instructions for the clamping devices UNITOP and UNITOP 250.

The fusion of the HD-PE distribution pipes and the house connections with FRIALEN Saddle with outlet spigot Universal SA UNI takes place by FRIALEN-fusing – leakproof and longitudinally strong.

The saddle and the outlet spigot have to be prepared according to the general installation instructions (see assembly instruction FRIALEN safety fittings). This involves removing the oxide skin and cleaning the pipe covered by the saddle.

For tapping of pipes without pressure please use the FRIATOOLS tapping equipment FWAB. Please refer the assembly and operating instructions of the drilling device FWAB. The fusion and tapping of pipes under pressure is possible with special tapping equipment. Please contact our applications engineers.

Good reasons for using the FRIALEN Saddle with outlet spigot Universal SA UNI:

Cost alternative to T-Pieces
Cross-dimensional processing of up to three pipe diameters
Clear and safe indication for the correct clamping (preset torque wrench)
Burr-free and almost flush tapping for maximum hydraulic performance
Tapping under pressure with shut-off element without interrupting operations is possible
Before tapping the pipe, a leak test can take place with the pressure testing device FWDPA SA
Simple and safe installation with UNITOP and UNITOP 250 (Balanced-Loading)
Fusion indicators for visual fusion control
