| Reference | tooltipImage | characteristics | Box units | measurement | A | B | C | D | E | diameterF | DN | Size | Weight kg |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 052308 | - | PVC Body | 30 | 20 | 155 | 60 | 48 | 45 | 42 | 20 | 15 | 20 | - |
| 052309 | - | PVC Body | 20 | 25 | 183 | 60 | 57 | 49 | 51 | 25 | 20 | 25 | - |
| 052310 | - | PVC Body | 15 | 32 | 206 | 75 | 69 | 61 | 54 | 32 | 25 | 32 | - |
| 052311 | - | PVC Body | 10 | 40 | 215 | 75 | 83 | 66 | 55 | 40 | 32 | 40 | - |
| 052312 | - | PVC Body | 10 | 50 | 252 | 94.5 | 96 | 79 | 65 | 50 | 40 | 50 | - |
| 052313 | - | PVC Body | 10 | 63 | 260 | 94.5 | 114 | 86 | 66 | 63 | 50 | 63 | - |
