Pressure pipe PVC-U PN10 forsheda

Tubo a pressione PVC-U PN10 UNI EN ISO 1452-2 Forsheda 601 Powerlock®, Grigio RAL 7011, lunghezza 6m.

Tubazioni a pressione per sistema di giunzione mediante saldatura chimica a freddo (incollaggio attraverso l’utilizzo di idoneo collante WELDON e primer detergente) o giunto a guarnizione preinserita e bloccata FORSHEDA 601 POWERLOCK®.

I tubi in PVC rigido Lareter per condotte in pressione sono garantiti dalle certificazioni rilasciate dall’IIP, da CSTB, DVGW, WRAS e IMO.

Go back Data sheet
Disegno del tubo a pressione in PVC-U Forsheda
Reference Other description system Category family series D (mm) S (mm) Lb (mm) Weight (kg/m) Qty x pallet
PIPEV21040S6L * Rubber ring VDA system Pipes PVC-A Pipe BS-PAS-27:1999 PN8 pipe 40* 1.9 100 0.36 275
PIPEV21050S6L * Rubber ring VDA system Pipes PVC-A Pipe BS-PAS-27:1999 PN8 pipe 50* 2.4 100 0.56 194
PIPEV21063F6L * Rubber ring VDA system Pipes PVC-A Pipe BS-PAS-27:1999 PN8 pipe 63 3 110 0.89 123
PIPEV21075F6L * Rubber ring VDA system Pipes PVC-A Pipe BS-PAS-27:1999 PN8 pipe 75 3.6 120 1.24 87
PIPEV21090F6L * Rubber ring VDA system Pipes PVC-A Pipe BS-PAS-27:1999 PN8 pipe 90 4.3 130 1.78 96
PIPEV26110F6L * Rubber ring VDA system Pipes PVC-A Pipe BS-PAS-27:1999 PN8 pipe 110 4.2 130 2.15 57
PIPEV26125F6L * Rubber ring VDA system Pipes PVC-A Pipe BS-PAS-27:1999 PN8 pipe 125 4.8 150 2.77 51
PIPEV26140F6L * Rubber ring VDA system Pipes PVC-A Pipe BS-PAS-27:1999 PN8 pipe 140 5.4 160 3.54 45
PIPEV26160F6L * Rubber ring VDA system Pipes PVC-A Pipe BS-PAS-27:1999 PN8 pipe 160 6.2 165 4.61 33
PIPEV26180S6L * Rubber ring VDA system Pipes PVC-A Pipe BS-PAS-27:1999 PN8 pipe 180 6.9 170 5.78 28
PIPEV26200F6L * Rubber ring VDA system Pipes PVC-A Pipe BS-PAS-27:1999 PN8 pipe 200 7.7 180 7.16 20
PIPEV26225F6L * Rubber ring VDA system Pipes PVC-A Pipe BS-PAS-27:1999 PN8 pipe 225 8.6 200 8.99 18
PIPEV26250F6L * Rubber ring VDA system Pipes PVC-A Pipe BS-PAS-27:1999 PN8 pipe 250 9.6 210 11.14 12
PIPEV26280F6L * Rubber ring VDA system Pipes PVC-A Pipe BS-PAS-27:1999 PN8 pipe 280 10.7 210 13.88 11
PIPEV26315F6L * Rubber ring VDA system Pipes PVC-A Pipe BS-PAS-27:1999 PN8 pipe 315 12.1 230 17.61 9
PIPEV26355F6L * Rubber ring VDA system Pipes PVC-A Pipe BS-PAS-27:1999 PN8 pipe 355 13.6 250 22.33 6
PIPEV26400F6L * Rubber ring VDA system Pipes PVC-A Pipe BS-PAS-27:1999 PN8 pipe 400 15.3 250 28.23 5
PIPEV26500F6L * Rubber ring VDA system Pipes PVC-A Pipe BS-PAS-27:1999 PN8 pipe 500 19.1 255 43.91 2

* Rubber ring
  • Gamma dimensionale: d 16 ÷ d 500 (mm)
  • Pressione nominale: PN 6-10-12,5-16-20-25 con acqua a 20 °C
  • Campo di temperatura: 0 °C ÷ 60 °C
  • Standard di accoppiamento
    • Incollaggio: EN ISO 15493, EN ISO 1452, DIN 8061/2.
    • Innesto: Guarnizione FORSHEDA 601 POWER-LOCK®
  • Riferimenti normativi
    • Criteri Costruttivi: EN ISO 15493, EN ISO 1452, DIN 8061/2
    • Metodi e requisiti dei test: EN ISO 15493, EN ISO 1452, DIN 8061/2
    • Criteri di installazione: DVS 2204, DVS 2221, UNI 11242, EN ISO 1452, DIN 8061/2
  • Materiale tubi: PVC-U grigio scuro RAL 7011
