Trap interceptor, red colour (O-Ring)

Injected molded sewer trap made of PVC-U designed for connections to piping systems conform to EN1329 and EN1401.

Redi trap interceptor has the following technical features:
- No hand welding
- SC or RR jointing type
- Optimal water seal (min. 3/10 diameter ratio) to prevent the passage of sewer gas
- Provided with 2 rodding access screw caps
- Blank vents inlets for the relief of sewer gases, admission of oxygen for aerobic sewage digestion and maintenance of the trap water seal

Supplier’s Quality system has to be ISO 9001 certified, supplier’s Environment system has to be ISO 14001 certified as a condition for purchase.

Standard lip ring
Go back Data sheet
Reference tooltipImage DN (mm) H sifonante (mm) DN1 (mm) S (mm) L1 (mm) L2 (mm) L3 (mm) L4 (mm) L5 (mm) L6 (mm) RAL
1751691 - 160 50 63 3,0 72 295 158 655 50 210 RAL 8023
1752091 - 200 50 63 4,0 84 345 198 795 50 270 RAL 8023

Certificates

Downloads

Trap interceptor A-N
570 KB, DOCX
Tender specifications REDI
