ULF0X.X.X
Ultra Low Flow Sensors
FLS compact Ultra Low Flow sensors ULF have been for use with every kind of aggressive and solid-free liquids. The sensor can be fixed to flexible or rigid pipes via 1/4” GAS threaded process connections. The paddlewheel sensor produces a frequency output proportional to the flow velocity that can be easily transmitted and processed. The ULF sensor offers two different flow ranges starting from 1.5 or 6 l/h (0.0066 or 0.0264 gpm). The construction materials, POM or ECTFE (Halar®), provide high strength and chemical resistance.
| Reference | tooltipImage | system | Category | family | series | Version | Power supply | Lenght | Main Wetted Materials | Enclosure | Flow Rate Range | Weight (gr.) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ULF01.H.0 | - | Automation system | FLS Measurement and control Instrumentation | Flow sensors | In line Ultra Low Flow and Oval Gear Sensors | Hall | 5 - 24 VCC | 77 mm | POM $ FKM | IP65 | From 1,5 to 100 l/h* | 170 |
| ULF01.H.2 | - | Automation system | FLS Measurement and control Instrumentation | Flow sensors | In line Ultra Low Flow and Oval Gear Sensors | Hall | 5 - 24 VCC | 77 mm | ECTFE $ FKM | IP65 | From 1,5 to 100 l/h* | 200 |
| ULF01.H.3 | - | Automation system | FLS Measurement and control Instrumentation | Flow sensors | In line Ultra Low Flow and Oval Gear Sensors | Hall | 5 - 24 VCC | 77 mm | ECTFE $ KALREZ | IP65 | From 1,5 to 100 l/h* | 200 |
| ULF01.R.0 | - | Automation system | FLS Measurement and control Instrumentation | Flow sensors | In line Ultra Low Flow and Oval Gear Sensors | Reed | None | 77 mm | POM $ FKM | IP65 | From 1,5 to 100 l/h* | 170 |
| ULF01.R.2 | - | Automation system | FLS Measurement and control Instrumentation | Flow sensors | In line Ultra Low Flow and Oval Gear Sensors | Reed | None | 77 mm | ECTFE $ FKM | IP65 | From 1,5 to 100 l/h* | 200 |
| ULF01.R.3 | - | Automation system | FLS Measurement and control Instrumentation | Flow sensors | In line Ultra Low Flow and Oval Gear Sensors | Reed | None | 77 mm | ECTFE $ KALREZ | IP65 | From 1,5 to 100 l/h* | 200 |
| ULF03.H.0 | - | Automation system | FLS Measurement and control Instrumentation | Flow sensors | In line Ultra Low Flow and Oval Gear Sensors | Hall | 5 - 24 VCC | 77 mm | POM $ FKM | IP65 | From 1,5 to 100 l/h* | 170 |
| ULF03.H.2 | - | Automation system | FLS Measurement and control Instrumentation | Flow sensors | In line Ultra Low Flow and Oval Gear Sensors | Hall | 5 - 24 VCC | 77 mm | ECTFE $ FKM | IP65 | From 1,5 to 100 l/h* | 200 |
| ULF03.H.3 | - | Automation system | FLS Measurement and control Instrumentation | Flow sensors | In line Ultra Low Flow and Oval Gear Sensors | Hall | 5 - 24 VCC | 77 mm | ECTFE $ KALREZ | IP65 | From 1,5 to 100 l/h* | 200 |
| ULF03.R.0 | - | Automation system | FLS Measurement and control Instrumentation | Flow sensors | In line Ultra Low Flow and Oval Gear Sensors | Reed | None | 77 mm | POM $ FKM | IP65 | From 1,5 to 100 l/h* | 170 |
| ULF03.R.2 | - | Automation system | FLS Measurement and control Instrumentation | Flow sensors | In line Ultra Low Flow and Oval Gear Sensors | Reed | None | 77 mm | ECTFE $ FKM | IP65 | From 1,5 to 100 l/h* | 200 |
| ULF03.R.3 | - | Automation system | FLS Measurement and control Instrumentation | Flow sensors | In line Ultra Low Flow and Oval Gear Sensors | Reed | None | 77 mm | ECTFE $ KALREZ | IP65 | From 1,5 to 100 l/h* | 200 |
APPLICATIONS:
- Water treatment
- Chemical industry
- Pharmaceutical industry
- Dosing systems
- Laboratory plants
MAIN FEATURES:
- POM or ECTFE (Halar®) wetted parts
- Two flow ranges available: - 1.5 - 100 l/h (0.0066 - 0.44 gpm) - 6 - 250 l/h (0.0264 - 1.1 gpm)
- High chemical resistance
- Easy mounting
