KBS
Installation kit for ball valves
Installation kit KBS for ball valves
- To operate the ball valves from the road cap downwards
- Wrench size SW14 (14 mm) and SW30 (30 mm)
- Telescopic bar:
- Length fitting
- Continuously adjustable (without tools)
- Self-supporting
- Corrosion protected (actuating element and coupling sleeve made of hot-dip galvanised cast steel, linkage made of hot-dip galvanised steel)
Note:
Stable seating for the sleeve pipe bell at the nominal size of 20-50, by means of a design comprising a housing.
| Reference | d | RD [m] | BX | PU | L min | L max | SW | Weight [kg] |
|---|---|---|---|---|---|---|---|---|
| 617586 | 20-50 | 0,62 - 0,79 | 1 | 42 | 350 | 520 | 30 + 14 | 2,000 |
| 617587 | 20-50 | 0,77 - 1,09 | 1 | 42 | 500 | 820 | 30 + 14 | 2,000 |
| 617588 | 20-50 | 1,02 - 1,59 | 1 | 42 | 750 | 1320 | 30 + 14 | 3,600 |
| 617589 | 20-50 | 1,27 - 2,09 | 1 | 42 | 1000 | 1820 | 30 + 14 | 4,450 |
| 617590 | 63-225 | 0,75 - 1,05 | 1 | 42 | 480 | 780 | 30 + 14 | 2,780 |
| 617591 | 63-225 | 1,00 - 1,56 | 1 | 42 | 730 | 1290 | 30 + 14 | 4,200 |
| 617592 | 63-225 | 0,98 - 1,79 | 1 | 42 | 1250 | 2060 | 30 + 14 | 4,950 |
Wrench size SW1 14 mm for use as a domestic connection fitting
Other lengths available on request.
For ball valve KH d50 with the same pipe, select variant d63-225
Areas of Application
Telescopic installation kit for operation of the FRIALEN KHP, KH, KHW, AKHP und AKHP-TL from the street cap.
Assembly Instructions
Before fusion, the FRIALEN KHP, KH, KHW, AKHP and AKHP-TL must be aligned to suit the type of actuation intended, in order to ensure that the installation kit KBS will seat correctly.
Good reasons for using the FRIALEN Installation kits KBS:
- Protective pipe of polyethylene protects from intrusion of sand or soil
- Assembly without tools
- Self supporting in any extended position
- Safe from being pulled out
- Corrosion protected
- Telescope assembly set can be adjusted even once in place and filled
- Constructive harmonizing of the transferable torque onto the FRIALEN Ball Valve
- Connection pins made from stainless steel
- Coloured marking disk for use with gas and water
- Parts of the protective pipe are fully welded together
