Invert reducer M/F
ULTRAMAX completed with AMAX fittings range is the push-fit polypropylene complete soil and waste system for civil and industrial waste water drainage.
EN 1451 Push-Fit PP Pipe and Fittings
Impact-Resistant
B1 Fire Reaction Class, Self-extinguishing
| note : | 1 |
| Reference | tooltipImage | Colour | D1 (mm) | L1 (mm) | L2 (mm) | d2 |
|---|---|---|---|---|---|---|
| Z5040PP | - | Grey RAL 7037 | 32 | - | - | 40 |
| Z5150PP | - | Grey RAL 7037 | 32 | 73 | 12 | 50 |
| Z5050PP | - | Grey RAL 7037 | 40 | 73 | 12 | 50 |
| Z5175PP | - | Grey RAL 7037 | 40 | 91 | 26 | 75 |
| Z5290PP | - | Grey RAL 7037 | 40 | - | - | 90 |
| Z5110PP | - | Grey RAL 7037 | 40 | - | - | 110 |
| Z5075PP | - | Grey RAL 7037 | 50 | 86 | 20 | 75 |
| Z5111PP | - | Grey RAL 7037 | 50 | 115 | 40 | 110 |
| Z5090PP | - | Grey RAL 7037 | 75 | - | - | 90 |
| Z5011PP | - | Grey RAL 7037 | 75 | 101 | 26 | 110 |
| Z5012PP | - | Grey RAL 7037 | 110 | 101 | 15 | 125 |
| Z5116PP | - | Grey RAL 7037 | 110 | 137 | 34 | 160 |
| Z5016PP | - | Grey RAL 7037 | 125 | 130 | 27 | 160 |
