ASA VL 160

Vacuum-loading sewage saddle

Vacuum-loading sewage saddle ASA TL, SDR 17

Compact component made from HD-PE with integrated fusion coupler in the outlet (d 160)
For a connection for connecting pipes to existing PE main channel
Safety technology

Note:

Can only be fused with the clamping system FRIALOAD.

Components: PUMP (Order No. 613810), PLATE (Order No. 617372) and FWAB ASA VL 160/450 (Order No.613846) or FWAB ASA VL 160/710 (Order No. 613816).

For installation on close-fit liners please contact our hotline +49 621 486-2325.

Go back Data sheet

PE 100

Maximum permissible working pressure 2.5 bar

	Reference	d₁	d₂	DN	BX	PU	t	H1	H2	B1	Weight kg
	682618	200	160	150	8	64	76	163	92	270	0,990
¹	682613	225 250	160	150	8	64	76	165	94	270	0,950
	682614	280	160	150	10	80	76	143	72	270	0,810
	682615	315	160	150	10	80	76	139	68	270	0,990
	682620	355	160	150	10	80	76	129	58	270	0,960
	682621	400	160	150	10	80	76	123	52	270	0,900
	682616	450	160	150	10	80	76	117	46	270	0,890
	682622	500/560/630	160	150	10	80	76	117	46	270	0,900

¹ When using d 250 pipes please contact the hotline +49 621 486-1896.

For installation on close-fit liner, please contact our hotline +49 621/486-1896.

Mounting with clamping device FRIALOAD.

Sewage pipe systems are high-value assets of a value which has to be maintained for a long time. Increasing demands on the public sewage system require materials which meet these criteria. HDPE sewage pipes have been fused for many years with the FRIAFIT HDPE sewage system tightly, frictionlocked and root-proof.

Areas of Application

Domestic connections to HDPE sewers: These have up to now been carried out using spigot fittings which are connected to the pipe system with heating coil couplers. Retrospective connection to domestic pipes is only possible if the sewer pipe system is separated which is time consuming. The FRIAFIT-Sewage Saddle ASA VL 160 allows to establish domestic sewer connections without having to separate the existing pipeline.

Assembly Instructions with vaccum clamping by clamping device FRIALOAD and tapping unit FWAB ASA d 160

The clamping force of the saddle required for fusion and build-up of the joining pressure is applied by a vacuum. This only requires the clamping device FRIALOAD. Typical out-of-roundnesses and shape deviations of the pipe can be bridged by the clamping method.

Good reasons for using the FRIAFIT-Sewage Saddle ASA VL 160

Economic establishing of domestic connections, particularly in areas with high density of development

Can be used with new installations, restoration and retrospective connections of sewer pipes

Minimal space required due to the compact component design. Pipe connections from HDPE are fused directly into the integrated heating coil coupler of the outlet socket

Direct integration of connecting pipes without misalignment or flow obstructions

No further components required due to integrated heating coil coupler in the outlet

Barcode for fully automatic fusion process with HDPE pipes from SDR 33 to SDR 11 in view of the surrounding temperature (compensation of the temperature)
