SUPER PLUS, activated sludge system
Non-collective treatment of domestic wastewater, from one housing unit (arround 5 person) up to 28 users. high effluent quality for discharge into surface.
water body
One-piece polyethylene packaged
| note : | Delivery includes: timer, activation enzymes, and chlorine disinfection tablet. Compressor needs to be installed outdoors and under cover. Compliance with standard: 2004/108/CE - 2006/95/CE |
| Use : | Suitable for treating domestic wastewater for subsequent discharge onto land. |
| Reference | tooltipImage | D (cm) | Height H (cm) | HE (cm) | HU (cm) | V ox (m3) | V sett (m3) | ØE e ØU (mm) | Power (Kw) | Item | Users (E.I.) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| IS09220 | - | 120 | 142 | 105 | 100 | 0,73 | 0,17 | 100 | 30 (W) | SUPER PLUS S.1 | 5 |
| IS09221 | - | 120 | 162 | 125 | 120 | 1,14 | 0,25 | 100 | 40 (W) | SUPER PLUS S.2 | 10 |
| IS09222 | - | 120 | 202 | 165 | 160 | 1,44 | 0,5 | 125 | 40 (W) | SUPER PLUS S.3 | 15 |
| IS09223 | - | 160 | 187 | 140 | 135 | 2,47 | 0,5 | 140 | 45 (W) | SUPER PLUS S.4 | 20 |
| IS09224 | - | 160 | 222 | 175 | 170 | 3,47 | 0,6 | 140 | 50 (W) | SUPER PLUS S.5 | 25 |
