WRK
Wide-Range Coupling
Wide-Range is the same as MaxiFit.
Coupling for connecting pipes made of different materials (steel, cast iron, ductile cast iron, asbestos cement, PVC, PE-HD/PEX).
- Housing and follower ring made of steel
- Rilsan corrosion protection (min. 250 µm according to GSK)
- Screws and nuts galvanized/sheraplex-coated or made of stainless steel
- Seal material EPDM
- Diameter tolerance max. 17 mm
- Pipes can be angled by max. 6 degrees
Note:
Our SHVA inner support sleeve is required for use on PE-HD/PEX pipes Alternatively, we recommend the longitudinally force-locking product FRIAGRIP.
Nuts and bolts galvanized and sheraplex coated Gasket EPDM, DIN-EN 681-1 / KTW / UBA / DVGW-W270
PFA /PN Water: up to DN 300 = 16 bar
| Reference | d | DN | BX | PU | L | Weight kg |
|---|---|---|---|---|---|---|
| GB-02R9-351 | 351,0-368,0 | 300 | 1 | 2 | 310 | 32,400 |
| GB-02R9-374 | 374,5-391,5 | 350 | 1 | 1 | 310 | 34,200 |
| GB-02R9-394 | 394,3-411,3 | 400 | 1 | 1 | 310 | 35,600 |
| GB-02R9-418 | 418,2-435,2 | 400 | 1 | 1 | 310 | 37,600 |
| GB-02R9-447 | 447,2-464,2 | 400 | 1 | 1 | 310 | 39,500 |
| GB-02R9-455 | 455,0-472,0 | 450 | 1 | 1 | 310 | 39,500 |
| GB-02R9-476 | 476,0-493,0 | 450 | 1 | 1 | 310 | 43,000 |
| GB-02R9-501 | 501,9-518,9 | 500 | 1 | 1 | 310 | 44,500 |
| GB-02R9-527 | 527,0-544,0 | 500 | 1 | 1 | 310 | 46,000 |
| GB-02R9-555 | 555,3-572,3 | 500 | 1 | 1 | 310 | 47,600 |
| GB-02R9-630 | 630,5-647,5 | 600 | 1 | 1 | 310 | 52,000 |
| GB-02R9-662 | 662,0-679,0 | 600 | 1 | 1 | 310 | 57,800 |
| GB-02R9-675 | 675,0-692,0 | 600 | 1 | 1 | 310 | 59,000 |
Nuts and Bolts Stainless steel ,Gasket EPDM, DIN-EN 681-1 / KTW / UBA / DVGW-W270
PFA /PN Water: up to DN 300 = 16 bar
| Reference | d | DN | BX | PU | L | Weight kg |
|---|---|---|---|---|---|---|
| GB-02R9X351 | 351,0-368,0 | 300 | 1 | 2 | 310 | 32,400 |
| GB-02R9X374 | 374,5-391,5 | 350 | 1 | 1 | 310 | 34,200 |
| GB-02R9X394 | 394,3-411,3 | 400 | 1 | 1 | 310 | 35,600 |
| GB-02R9X418 | 418,2-435,2 | 400 | 1 | 1 | 310 | 37,600 |
| GB-02R9X447 | 447,2-464,2 | 400 | 1 | 1 | 310 | 39,100 |
| GB-02R9X455 | 455-0-472,0 | 450 | 1 | 1 | 310 | 39,500 |
| GB-02R9X476 | 476,0-493,0 | 450 | 1 | 1 | 310 | 43,000 |
| GB-02R9X501 | 501,9-518,9 | 500 | 1 | 1 | 310 | 44,500 |
| GB-02R9X527 | 527,0-544,0 | 500 | 1 | 1 | 310 | 47,700 |
| GB-02R9X555 | 555,3-572,3 | 500 | 1 | 1 | 310 | 47,600 |
| GB-02R9X630 | 630,5-647,5 | 600 | 1 | 1 | 310 | 56,100 |
| GB-02R9X662 | 662,0-679,0 | 600 | 1 | 1 | 310 | 57,800 |
| GB-02R9X675 | 675,0-692,0 | 600 | 1 | 1 | 310 | 59,000 |
| GB-02R9X689 | 689,0-706,0 | 700 | 1 | 1 | 310 | 56,300 |
| GB-02R9X695 | 695,0-712,0 | 700 | 1 | 1 | 310 | 56,700 |
| GB-02R9X710 | 710,0-727,0 | 700 | 1 | 1 | 310 | 57,700 |
| GB-02R9X733 | 733,0-750,0 | 700 | 1 | 1 | 310 | 60,100 |
